Description
Slant Bed CNC Lathe CKL Series
1.Robust casting bed with 45° combines inherent rigidity.
2. Precison Linea rail ensure rigidity, accuracy, long lifespan.
3.Hydrculic Chuck improved the efficiency and productivity.
Technical Parameters:
| Model | CK40L | CK50L |
| Max. swing over bed (mm) | 400 | 540 |
| Max. swing over carriage(mm) | 280 | 350 |
| Max. cutting length(mm) | 500/750 | 500/750 |
| Max. spindle speed(r/min) | 4500 | 3000 |
| Spindle nose | A2-6 | A2-8 |
| Spindle bore(mm) | Φ62 | Φ90 |
| Bar diameter(mm) | Φ48 | Φ75 |
| Hydraulic chuck (mm/Inch) | 200 / 8″ | 250 / 10″ |
| Spindle motor power(kw) | 7.5/11 ( servo) | 11/15 ( servo) |
| Tool number (pcs) | Hydraulic: 8 | Hydraulic: 8 /12 |
| Tool Shank size(mm) | 25*25 | 25*25 |
| X Axis travel(mm) | 240 | 280 |
| Z Axis travel(mm) | 500/750 | 750 |
| X/Z Axis rapid feeding(m/min) | 18 / 20 | 18 / 20 |
| Max. Cutting feed speed(mm/min) | 5000 | 5000 |
| Tail stock ( Dia/ travel) | MT5 75 / 80 | MT5 90 / 120 |
| Weight (kg) | 3000 | 4500 |
| Overall dimension(mm) | 2800/3150x1800x1800 | 3500/3850×1900×1900 |
